Description
Sharp LCD SCREEN LQ121S1DG41

Brand	Sharp
Model Name	LQ121S1DG41
Screen size	12.1"
Screen type	LCM, a-Si TFT-LCD
Resolution	800(RGB)×600 [SVGA] 82PPI
Pixel configuration	RGB vertical bar
Display size	246 × 184.5 mm (H×V)
physical dimension	276 × 209 × 11 mm (H×V×D)
Visual size	249.0 × 187.5 mm (H×V)
Surface treatment	Matte, Hard coating (3H)
Brightness (cd/m²)	370 (Typ.)
Contrast	450: 1 (Typ.) [Transmission]
Best angle	6 o'clock
Optical mode	TN, normally white display, transmissive
Viewing angle	70/70/50/60 (Typ.)(CR≥10)
responding speed	10/25 (Typ.)(Tr/Td) ms
Number of colors	262K, 50% NTSC
Backlight type	2 pcs CCFL, 50K hours, no driver
Screen weight	660g (Max.)Apply toindustry
Touch function	No touch
signal system	Parallel RGB (1 ch, 6-bit), connector, 41 pins
Supply voltage	3.3/5.0V (Typ.)(VCC)
Maximum rating	Storage temperature: -30 ~ 70 °C Working temperature: -10 ~ 65 °C
