G270ZAN02.1 Information:

Brand	AUO
Model	G270ZAN02.1
Diagonal Size	27.0"
Type	a-Si TFT-LCD, LCM
Pixel Number	3840(RGB)×2160, UHD, 16:9
Dot Layout	RGB Vertical Stripe
Active Area	596.16(W)×335.34(H) mm
Panel Weight	3.20/3.36Kgs (Typ./Max.)
Outline Size	630(W)×368.2(H)×19.8(D) mm
Surface	Glare (Haze 0%)
Brightness	850 cd/m² (Typ.)
Contrast Ratio	2000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	10/12 (Typ.)(Tr/Td) ms
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Operating Mode	AHVA, Normally Black, Transmissive
Support Color	1.07B, 98% DCI-P3
Designed For	Industrial/Medical Imaging/Outdoor High Brightness
Power Cons.	46.6W (Typ.)
Light Source	WLED, 30K hrs, Without Driver
Frame Rate	60Hz
Touch Panel	Without
Interface Type	eDP (4 Lanes), HBR2 (5.4G/lane), 51 pins Connector
Power Supply	12.0V (Typ.)
Environment	Operating Temp. 0 ~ 50 °C, Storage Temp. -20 ~ 60 °C
