HSD088KPW1-A10 Products Description:
|
HannStar LCD Screen HSD088KPW1-A10 |
|
|
Panel Brand |
HannStar |
|
Model P/N |
HSD088KPW1-A10 |
|
Diagonal Size |
8.8" (Native bar) |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
1920×480(RGB) 222PPI |
|
Pixel Format |
RGB Horizontal Stripe |
|
Active Area |
218.88(W)×54.72(H) mm |
|
Outline(mm) |
231.3(W)×64.3(H)×5.1(D) |
|
Treatment |
Hard coating |
|
Luminance |
600 (Typ.)(cd/m²) |
|
Contrast Ratio |
800 : 1 (Typ.) (TM) |
|
Viewing Angle |
85/85/85/85 (Typ.)(CR≥10) |
|
Work Mode |
IPS Pro, Normally Black, Transmissive |
|
Good View at |
Symmetry |
|
Response |
40 (Typ.)(Tr+Td) ms |
|
Color Depth |
16.7M 50% NTSC |
|
Backlight |
WLED , 30K hours , No Driver |
|
Mass |
110g (Typ.) |
|
Used for |
Stretched Bar LCD / Automotive Display |
|
Refresh Rate |
60Hz |
|
Touchscreen |
Without |
|
Signal Type |
MIPI (4 data lanes) , 40 pins Connector |
|
Voltage Supply |
3.3/12.0/18.0/-10.0V (Typ.)(VDD/AVDD/VGH/VGL) |
|
Max. Ratings |
Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
|
8.8 inch HSD088KPW1-A10 1920*480(RGB) high resolution TFT LCD Screen LCD Display |
|
HSD088KPW1-A10 Product Usage:

HSD088KPW1-A10 Shipping:

HSD088KPW1-A10 REFUND&EXCHANCE :
1.If you are not satisfied with your purchase, you can exchange the items received, but you must contact us within 3 days of receiving your order, but you must pay for all additional shipping fees incurred and returned items which must be kept In its original state.
2.If you wish to exchange goods shipped defective or wrong, please contact us within 3 days after receiving the goods.
3.Keep in mind that for the exchange of part we will send it as soon as we receive the returned item
HSD088KPW1-A10 FAQ:
Q: Do you accept sample orders of HSD088KPW1-A10 ?
A: Of course! Sample order is welcome.
Q: Can I pay my order of HSD088KPW1-A10 vai credit card?
A: Yes! You can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90 days warranty.
Q: If I place order now, when will you ship the goods of HSD088KPW1-A10 ?
A: The order will be shipped within 2-3 working days after received your payment.
HSD088KPW1-A10 Contact information:
tel: +86-18575563918
Phone: +86-18575563918
Envelope: chance@yongs-hk.com
Address:Shenzhen, China
Whatsapp: +86-18575563918
Skype: +86-18575563918
Wechat: +86-18575563918
Hot Tags: 8.8 inch hsd088kpw1-a10 1920*480(rgb) high resolution tft lcd screen lcd display, China, suppliers, wholesale, buy, cheap, discount, low price, in stock
