LG Display LCD SCREEN LD430EUE-FHC1

Manufacturer	LG Display
Model Name	LD430EUE-FHC1
Screen Size	43 inch
Types of	a-Si TFT-LCD, LCD module
Resolution	1920(RGB)×1080 FHD 51PPI
Pixel arrangement	RGB vertical bar
Display area	941.184(H)×529.416(V) mm
physical dimension	963.6(H)×567.9(V) mm
Open area	945.8(H)×534.02(V) mm
Surface treatment	Matte (Haze 1%), Hard coating (3H)
Display brightness	300 cd/m2 (Typ.)
Contrast	1000:1 (Typ.) (transmission)
Recommended perspective	Full view
Response time	12 (Typ.)(Tr+Td) ms
Viewing angle	89/89/89/89 (Min.)(CR≥10)
Display mode	S-IPS, normally black display, transmissive
Support color	16.7M, 68% NTSC
type of light source	WLED [2 strings], 50K hours, no driver
weight	7.50Kgs (Typ.)
Frame rate	60Hz
Interface Type	51 pins LVDS (2 ch, 8-bit), Connector
Voltage supply	12.0V (Typ.)
Application Environment	Working temperature: 0 ~ 50 °C; Storage temperature: -20 ~ 60 °C
