PANDA LCD Screen LC215DU2A | |
Manufacturer | PANDA |
Model Name | LC215DU2A |
Screen Size | 21.5 inch |
Screen Type | CELL, a-Si TFT-LCD |
Pixel Number | 1920(RGB)×1080 (FHD) 102PPI |
Arrangement | RGB Vertical Stripe |
Active Area(mm) | 476.64 × 268.11 (H×V) |
Outline(mm) | 487.54 × 282.91 × 1.34 (H×V×D) |
Treatment | Antiglare, Hard coating (3H) |
Luminance | 0 cd/m² |
Contrast Ratio | 3000 : 1 (Typ.) (TM) |
Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
Response | 25 (Typ.)(Tr+Td) ms |
Good View at | Symmetry |
Work Mode | VA, Normally Black, Transmissive |
Glass Thickness | 0.50+0.50 mm |
Transmissivity | 4.0% (Typ.)(with Polarizer) |
Color Depth | 16.7M 72% NTSC |
Backlight | No B/L |
Used for | Desktop Monitor |
Refresh Rate | 60Hz |
Touchscreen | Without |
Driver IC list | Built-in COF 6 source +3 gate chips |
Signal Type | LVDS (2 ch, 8-bit) , Connector 30 pins |
Voltage Supply | 5.0V (Typ.) |
Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
New Original LC215DU2A 14.0 Inch Laptop LCD Panel Touch Screen Assembly | |
Specific laptop models can come in many sizes and resolutions. Laptop LCD resolution should not beupgraded or downgraded. You must confirm that this screen matches your laptop in size and in resolution before you purchase! No Returns Due To Improper Installation or Incompatibility
Product line：
Laptop lcd and led screen:from 4.5 inch to 18.4 inch
1.Size:8.9",10.1",10.2",11.1",11.6",12.1",13.1,13.3",14.0",14.1" ,15.0",15.4",15.6",16. 0",17.0",17.3",18.4"and so on.
2. Resolution:WSVGA,WXGA,WXGAHD,XGA,WXGA+,WXGA++
3. Backlight:LED,1CCFL,2CCFL
Q: Can you tested the LC215DU2A before shipping ?
A: Of course , our lcd panel LC215DU2A was Strictly tested before shipping.
Q: How to order PANDA LC215DU2A ?
A: We accept T/T , Paypal , western union .
Q: How long the warranty of the lcd LC215DU2A ?
A: 90 days .
Q: What happen if the lcd panel LC215DU2A I received can't work ?
A: PANDA LC215DU2A was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
