TIANMA LCD SCREEN TM101JDHG33 | |
manufacturer | TIANMA |
Model Name | TM101JDHG33 |
screen size | 10.1 inch |
Screen type | a-Si TFT-LCD , LCM |
Resolution | 1280(RGB)×800, WXGA, 149PPI |
Pixel configuration | RGB Vertical Stripe |
Display size | 216.96(W)×135.6(H) mm |
physical dimension | 229.8(W)×149(H) ×9.6(D) mm |
Visual size | 219.96(W)×138.6(H) mm |
surface treatment | Hard coating |
Brightness | 900 cd/m² (Typ.) |
Contrast | 700:1 (Typ.) (TM) |
Best angle | Symmetry |
Optical mode | SFT, Normally Black, Transmissive |
Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
Responding time | 25 (Typ.)(Tr+Td) |
Number of color | 262K/16.7M 50% NTSC |
Backlight type | WLED , 40K hours , With LED Driver |
Panel weight | 280g (Typ.) |
Apply to | Industrial / Medical Imaging / Outdoor High Brightness |
Refresh rate | 60Hz |
Touch function | No touch |
signal system | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
Supply voltage | 3.3V (Typ.) |
Maximum rating | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -40 ~ 80 °C |
Lcd Monitors 10.1 inch TM101JDHG33 TFT LCD Panel Screen Display | |
About the warranty：
1: If the product is damaged during the warranty period, we can replace it for you for free or give you a full refund. For some high value products, buyers need to return the package to us.
2: If there is any problem with the product, we will try our best to solve the problem and provide good after-sales service. Please keep in touch with us.
Q: How long will I receive my goods TM101JDHG33 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment of TM101JDHG33 ?
A: We accept T/T , Paypal , western union .
Q: Can you give me a discount if I need a large quantity of TM101JDHG33 ?
A: Of course！If you make a large order, we will give you a discount.
Q: If I place order now，when will you ship the goods of TM101JDHG33 ?
A: The order will be shipped within 2-3 working days after received your payment.
