Description
NEC LCD SCREEN NL6448BC33-53
| Manufacturer | NEC |
Model Name | NL6448BC33-53 |
Screen Size | 10.4 inches |
Types of | a-Si TFT-LCD, LCM |
Resolution | 640(RGB)×480 VGA 76PPI |
Pixel arrangement | RGB vertical bar |
Display area | 211.2(H)×158.4(V) mm |
physical dimension | 243(H)×185.1(V) ×11(T) mm |
Open area | 215.4(H)×161.8(V) mm |
Surface treatment | Clear, Hard coating (3H) |
Display brightness | 380 cd/m² (Typ.) |
Contrast | 500:1 (Typ.) (transmission) |
Recommended perspective | Full view |
Response time | 18/16 (Typ.)(Tr/Td) ms |
Viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
Display mode | SA-SFT, normally black display, transmissive |
Support color | 262K, 40% NTSC |
type of light source | CCFL [2 pcs], no driver |
weight | 475/500g (Typ./Max.) |
Frame rate | 60Hz |
Touch technology | No touch |
Interface Type | 31 pins CMOS (1 ch, 6-bit), connector |
Voltage supply | 3.3/5.0V (Typ.)(VCC) |
Application Environment | Working temperature: -10 ~ 70 °C; Storage temperature: -20 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²) |
Q: How long will I receive my goods NL6448BC33-53?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q:Can you give me a discount if I need a large quantity of NL6448BC33-53?
A:Of course！If you make a large order, we will give you a discount.
Q:Do you accept sample orders of NL6448BC33-53 ?
A:Of course!sample order is welcome !
Q:Can I pay my order of NL6448BC33-53 via credit card ?
A:Yes！you can use your credit card through your Paypal account.
