Description
NEC LCD SCREEN NL10276BC30-33D
| Manufacturer | NEC |
Model Name | NL10276BC30-33D |
Screen Size | 15.0 inch |
Panel type | a-Si TFT-LCD, LCM |
Number of pixels | 1024(RGB)*768, XGA, 85PPI |
Pixel layout | RGB vertical bar |
Display area | 304.128(W)*228.096(H) mm |
Viewable area | 307.4(W)*231.3(H) mm |
physical dimension | 326.5(W)*253.5(H) *12(D) mm |
Surface treatment | Matte, Hard coating (3H) |
Panel brightness | 400 cd/m² (Typ.) |
Contrast | 500:1 (Typ.) (TM) |
Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
Operating mode | TN, normally white display, transmissive |
Reaction time | 3/15 (Typ.)(Tr/Td) ms |
Display color | 16.7M, 50% NTSC |
type of light source | 2 pcs CCFL, without driver |
working frequency | 60Hz |
touch screen | No touch |
Panel weight | 0.97/1.05Kgs (Typ./Max.) |
Signal interface | LVDS (1 ch, 8-bit), 20 pins, connector |
Drive screen voltage | 3.3V (Typ.) |
working environment | Working: -20 ~ 70 °C; Storage: -20 ~ 80 °C |
Q:Do you accept sample orders of NL10276BC30-33D ?
A:Of course!sample order is welcome !
Q:Can you give me a discount if I need a large quantity of NL10276BC30-33D ?
A:Of course！If you make a large order, we will give you a discount.
Q:How to make payment of NL10276BC30-33D ?
A:We accept T/T , Paypal , western union .
Q:How can I trace my order of NL10276BC30-33D A ?
A:we will give you tracking number then you can trace your order from website.
