Description
NEC LCD SCREEN NL8060BC21-11F
| Manufacturer | NEC |
Model Name | NL8060BC21-11F |
Screen Size | 8.4 inch |
Panel type | a-Si TFT-LCD, LCM |
Number of pixels | 800(RGB)*600, SVGA, 119PPI |
Pixel layout | RGB vertical bar |
Display area | 170.4(W)*127.8(H) mm |
Viewable area | 174.0(W)*131.4(H) mm |
physical dimension | 200(W)*152(H) *8.7(T) mm |
Surface treatment | Clear, Hard coating (3H) |
Panel brightness | 800 cd/m² (Typ.) |
Contrast | 800:1 (Typ.) (TM) |
Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
Operating mode | TN, normally white display, transmissive |
Reaction time | 3/15 (Typ.)(Tr/Td) ms |
Display color | 262K/16.7M, 40% NTSC |
type of light source | 4 strings WLED, 70K hours, without driver |
working frequency | 60Hz |
touch screen | No touch |
Panel weight | 260/280g (Typ./Max.) |
Signal interface | LVDS (1 ch, 6/8-bit), 20 pins, connector |
Drive screen voltage | 3.3V (Typ.) |
working environment | Work: -30 ~ 80 °C; Storage: -30 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²) |
