Description
NEC LCD SCREEN NL8060BC26-30D
| Manufacturer | NEC |
Model Name | NL8060BC26-30D |
Screen Size | 10.4 inch |
Types of | a-Si TFT-LCD, LCD module |
Resolution | 800(RGB)*600 SVGA 96PPI |
Pixel arrangement | RGB vertical bar |
Display size | 211.2 * 158.4 mm (H*V) |
physical dimension | 243 * 185.1 * 11 mm (H*V*D) |
Visual size | 215.4 * 161.8 mm (H*V) |
Surface treatment | Matte, Hard coating (3H) |
Brightness (cd/m²) | 400 (Typ.) |
Contrast | 1000: 1 (Typ.) [Transmission] |
Optical mode | TN, normally white display, transmissive |
Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
responding speed | 3/15 (Typ.)(Tr/Td) ms |
Number of colors | 262K/16.7M, 40% NTSC |
Backlight type | 2 pcs CCFL, 50K hours, no driver |
Screen weight | 475/500g (Typ./Max.) |
Refresh rate | 60Hz |
Touch function | No touch |
signal system | LVDS (1 ch, 6/8-bit), connector, 20 pins |
Supply voltage | 3.3V (Typ.) |
Maximum rating | Storage temperature: -30 ~ 80 °C Working temperature: -20 ~ 70 °C; Vibration resistance: 2.0G (19.6 m/s²) |
