Description
NEC LCD SCREEN NL10276BC13-01C
| Manufacturer | NEC |
Model Name | NL10276BC13-01C |
Screen Size | 6.5 inch |
Screen type | LCM, a-Si TFT-LCD |
Resolution | 1024(RGB)*768 [XGA] 196PPI |
Pixel configuration | RGB vertical bar |
Display size | 132.096 * 99.072 mm (H*V) |
physical dimension | 153 * 118 * 9.5 mm (H*V*D) |
Visual size | 135.9 * 102.8 mm (H*V) |
Surface treatment | Clear, Hard coating (2H), anti-reflection treatment |
Brightness (cd/m²) | 650 (Typ.) |
Contrast | 500: 1 (Typ.) [Transmission] |
Best angle | 6 o'clock |
Optical mode | TN, normally white display, transmissive |
Viewing angle | 80/80/80/60 (Typ.)(CR≥10) |
responding speed | 6/19 (Typ.)(Tr/Td) ms |
Number of colors | 262K/16.7M, 36% NTSC |
Backlight type | 6 strings WLED, 16K hours, no driver |
Screen weight | 170/190g (Typ./Max.) |
Refresh rate | 60Hz |
signal system | LVDS (1 ch, 6/8-bit), connector, 20 pins |
Supply voltage | 3.3V (Typ.) |
Maximum rating | Storage temperature: -30 ~ 80 °C Working temperature: -20 ~ 70 °C; Vibration resistance: 2.0G (19.6 m/s²) |
