Panel Brand | BOE | Panel Model | DV270FHB-P20 |
Panel Size | 27.0" | Panel Type | a-Si TFT-LCD, CELL |
Resolution | 1920(RGB)×1080, FHD, 81PPI | Pixel Format | RGB Vertical Stripe |
Display Area | 597.888(W)×336.312(H) mm | Bezel Opening | - |
Outline Size | 607.048(W)×346.642(H) mm | Surface | Antiglare (Haze 2.5%) , Hard coating (3H) |
Brightness | 0 cd/m² | Contrast Ratio | 1000:1 (Typ.) (TM) |
Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | Display Mode | ADS,NormallyBlack,Transmissive |
Best View on | Symmetry | Response Time | 14 (Typ.)(G to G) |
Glass Depth | 0.50+0.50 mm | Transmissivity | 5.1% (Typ.)(with Polarizer) |
Display Colors | 16.7M 99% sRGB | Lamp Type | No B/L |
Frequency | 60Hz | Touch Screen | Without |
Panel Weight | 657g (Typ.) | Application | Digital Signage |
Driver IC | - | ||
Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
Input Voltage | 5.0V (Typ.) | ||
Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C | ||
