Panel Brand | BOE | Panel Model | VS019U0M-NH0-DKP0 |
Panel Size | 1.9" | Panel Type | LTPS TFT-LCD , LCM |
Resolution | 1600(RGB)×1200, UXGA, 1058PPI | Pixel Format | RGB Vertical Stripe |
Display Area | 38.4(W)×28.8(H) mm | Bezel Opening | - |
Outline Size | 41.2(W)×40.6(H) ×1.82(D) mm | Surface | Hard coating (3H) |
Brightness | 1000 cd/m² (Typ.) | Contrast Ratio | 550:1 (Typ.) (TM) |
Viewing Angle | 25/25/35/35 (Typ.)(CR≥100) | Display Mode | ADS,NormallyBlack,Transmissive |
Best View on | - | Response Time | 5.5 (Max.)(G to G) |
Glass Depth | - | Transmissivity | - |
Display Colors | 16.7M 71% NTSC | Lamp Type | 4S4P WLED , Without Driver |
Frequency | 120Hz | Touch Screen | Without |
Panel Weight | 7.0±1.0g | Application | HMD VR AR |
Driver IC | - | ||
Signal Interface | MIPI (2 ch, 4 data lanes) , 50 pins Connector | ||
Input Voltage | 1.8/6.0/-6.0V (Typ.)(VDD/AVDD/AVEE) | ||
Environment | Operating Temp.: -10 ~ 55 °C ; Storage Temp.: -30 ~ 70 °C | ||
