Brand |
Samsung |
|
Model P/N |
LTV250QV-F07 |
|
Diagonal Size |
2.5" |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
320(RGB)×240, QVGA 162PPI |
|
Pixel Format |
RGB Delta |
|
Active Area |
49.946(W)×37.44(H) mm |
|
Bezel Opening |
52.7(W)×40.4(H) mm |
|
Outline Dim. |
56.1(W)×48(H)×2.97(D) mm |
|
Luminance |
250 cd/m² (Typ.) |
|
View Direction |
Symmetry |
|
Viewing Angle |
80/80/80/80 (Typ.)(CR≥10) |
|
Support Color |
16.7M 49% NTSC |
|
Weight |
16.4g (Typ.) |
|
Frame Rate |
- |
|
Treatment |
- |
|
Contrast Ratio |
500:1 (Typ.) (TM) |
|
Response Time |
25 (Typ.)(Tr+Td) |
|
Operating Mode |
PVA, Normally Black, TMR |
|
Light Source |
WLED [3S1P], W/O Driver |
|
Designed For |
Digital Still Camera,Digital Video Camera |
|
Touch Panel |
Without |
|
Interface Type |
Serial RGB (8-bit) + SPI49 pins FPC |
|
Power Supply |
3.0V (Typ.) |
|
Environment |
Operating Temperature: -20 ~ 60 °C; Storage Temperature: -30 ~ 70 °C |
