MV340VWM-CX0 LCD Panel Tracking Information:

Brand	BOE
Model Name	MV340VWM-CX0
Display Size	34 inch
Panel Type	a-Si TFT-LCD, LCM
Number of dots	3440(RGB)×1440, 21:9
Dot Layout	RGB Vertical Stripe
Active Area	799.8×334.8 mm (H×V)
Outline Area	812.05×353.6 mm (H×V)
Weight	4.19Kgs (Typ.)
Surface Feature	Antiglare (Haze 25%), Hard coating (3H)
Luminance	350 cd/m² (Typ.)
Contrast Ratio	1500:1 (Typ.) (TM)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Response (ms)	14 (Typ.)(G to G) ms
Good View at	Symmetry
Display Type	ADS, Normally Black, Transmissive
Display Colors	1.07B, 92% DCI-P3, Low Blue Light
Used for	Desktop Monitor
Power Cons.	34.52/36.52W (Typ./Max.)
Backlight	4 strings × 2CN WLED, 30K hrs, No Driver
Refresh Rate	100Hz
Touchscreen	Without
Signal Type	eDP (4 Lanes), HBR2 (5.4G/lane), 30 pins 0.5mm Connector
Voltage Supply	10.0V (Typ.)
Max. Ratings	Storage Temp. -20 ~ 60 °C Operating Temp. 0 ~ 50 °C

MV340VWM-CX0 LCD Panel Strict quality inspection：

All panels undergo rigorous quality checks prior to factory release and export. Please inspect the parcel immediately upon receipt. If you find missing items or transit damage, refuse acceptance and contact us right away.

Integrity is our core principle for online business. As a strategic partner of Alibaba, we maintain stringent product control standards. Before shipment, every item passes three-stage inspections conducted by procurement, QC and warehouse teams to guarantee product qualification.

Please check the goods promptly after delivery. In rare cases where quality issues occur, kindly provide photos as supporting evidence for us to proceed.

MV340VWM-CX0 LCD Panel Product Usage：

MV340VWM-CX0 LCD Panel note：

Purchasing Notes:

LCD screens come in a wide range of types, sizes, models and specifications. Product photos are for reference only and may not be identical to the actual item. Please contact us before placing your order to confirm compatibility with your device brand and model, to avoid issues caused by incorrect specification selection.

Return & Exchange Policy:

Please inspect and test your equipment promptly after receipt. For quality issues (non-human damage), you may apply for return or exchange within 7 days of delivery, and we will cover the shipping cost. Claims submitted after 7 days will be at the buyer's expense for shipping.

Returns or exchanges for non-quality reasons require the product to remain in resalable condition. All related shipping fees shall be borne by the buyer. We do not offer 7-day unconditional returns.
