Manufacturer | AUO | Model Name | C070VW02 V1 |
Screen Size | 7.0 inch | Screen Type | LCM , a-Si TFT-LCD |
Pixel Number | 800(RGB)×480 (WVGA) 133PPI | Arrangement | RGB Vertical Stripe |
Active Area(mm) | 152.4 × 91.44 (H×V) | Outline(mm) | 170.8 × 107.95 × 21.5 (H×V×D) |
Bezel Area(mm) | 153.6 × 92.64 (H×V) | Treatment | Antiglare (Haze 40%), Hard coating (3H) |
Luminance | 350 (Min.)(cd/m²) | Contrast Ratio | 300 : 1 (Typ.) (TM) |
Viewing Angle | 60/60/40/60 (Typ.)(CR≥10) | Response | 20/30 (Max.)(Tr/Td) ms |
Good View at | 6 o'clock | Work Mode | TN, Normally White, Transmissive |
Glass Thickness | - | Transmissivity | - |
Color Depth | 262K | Backlight | 4S4P WLED , 10K hours , No Driver |
Mass | 300±30g | Used for | Automotive Display |
Refresh Rate | - | Touch Screen | 4-wire Resistive Touch |
Driver IC list | - | ||
Signal Type | TTL (1 ch, 6-bit) , 82 pins Connector | ||
Voltage Supply | 3.3/9.8/15/-7V (Typ.)(VDD/AVDD/VGH/VGL) | ||
Max. Ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 80 °C | ||
