Manufacturer |
BOE |
Model Name |
MV282CVB-N10 |
|
Screen Size |
28.2 |
Panel Type |
a-Si TFT-LCD, CELL , FOB |
|
Resolution |
3840(RGB)×2560 163PPI |
Pixel Format |
RGB Vertical Stripe |
|
Active Area(mm) |
596.16(W)×397.44(H) mm |
Outline(mm) |
604.96(H)×408.14(V) ×1.13(D) mm |
|
Bezel Area(mm) |
- |
Treatment |
Antiglare (Haze 25%), Hard coating (3H) |
|
Luminance |
0 cd/m² (Typ.) |
Contrast Ratio |
1200:1 (Typ.) (TM) |
|
Viewing Angle |
89/89/89/89 (Typ.)(CR≥10) |
Response |
8 (Typ.)(G to G) |
|
Good View at |
- |
Operating Mode |
ADS, Normally Black, Transmissive |
|
Display Colors |
1.07B 97% DCI-P3 |
Light Source |
No B/L |
|
Weight |
676g (Typ.) |
||
|
Refresh Rate |
60Hz |
||
|
Driver IC list |
- |
||
|
Signal Type |
eDP (8 Lanes) , eDP1.2 , 50 pins Connector |
||
|
Voltage Supply |
12V (Typ.) |
||
|
Max. Ratings |
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
||
