Brand |
Samsung |
|
Model P/N |
LTN154CT02-001 1 Compatible |
|
Diagonal Size |
15.4" |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
1920(RGB)×1200, WUXGA 147PPI |
|
Pixel Format |
RGB Vertical Stripe |
|
Active Area |
331.2(W)×207(H) mm |
|
Bezel Opening |
335.0(W)×210.7(H) mm |
|
Outline Size |
344(W)×225(H)×7(D) mm |
|
Surface |
Antiglare (Haze 40%), Hard coating (3H) |
|
Brightness |
340 cd/m² (Typ.) |
|
Contrast Ratio |
500:1 (Typ.) (TM) |
|
Viewing Angle |
55/55/45/45 (Min.)(CR≥10) |
|
Display Mode |
TN, Normally White, Transmissive |
|
Best View on |
- |
|
Response Time |
16 (Typ.)(Tr+Td) |
|
Display Colors |
262K 72%NTSC |
|
Lamp Type |
2 pcsCCFL, 15K hours, Without Driver |
|
Frequency |
60Hz |
|
Touch Screen |
Without |
|
Shape Style |
Wedge (PCBA Bent, T≥5.2mm) |
|
Application |
Laptop |
|
Signal Interface |
LVDS (2 ch, 6-bit), 30 pinsConnector |
|
Input Voltage |
3.3V (Typ.) |
|
Environment |
Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
